Elbow Busbar Assembly Machine
Suzhou Kiande Electric Co., Ltd. is one of the most reliable manufacturers and suppliers of elbow busbar assembly machine in China. We are committed to providing high quality custom service and OEM&ODM service to global clients. If you're going to buy CE approved elbow busbar assembly machine made in China, welcome to get quotation from our factory. For price consultation, contact us.
KIANDE elbow busbar assembly machine for vertical and horizontal elbow riveting. Pneumatic clamping holds conductors firmly in position. Customizable to different busbar dimensions.
The KIANDE Elbow Busbar Assembly Machine is engineered to rivet horizontal and vertical elbow busbars. Pneumatic clamps hold conductors steadily, and the machine can be tailored to suit a wide range of busbar sizes.
Leveraging precision mechanical positioning alongside pneumatic and hydraulic clamping, the equipment automatically aligns elbow housings, insulators and conductive busbars. Servo systems adjust angles and gaps, followed by automatic clamping, locking and bonding to assemble multiple conductive busbars with elbow parts.
Limit sensors and synchronous drives precisely manage assembly clearances and coaxiality. All processes including feeding, positioning, joining and compaction run automatically based on preset programs without manual alignment. This delivers consistent, standardized assembly for angled busbar components and ensures stable assembly quality and structural soundness.
Selling Points:
Pneumatic clamping ensures tight, consistent conductor alignment during riveting
01
Handles both horizontal and vertical elbow types in one machine
02
3 clamping fixtures for secure multi-point fixation
03
Customizable to your busbar dimensions
04
Compact footprint at 1800×1800×900mm - fits into existing production layouts
05
Elbow Busbar Assembly Machine:
| Parameter | Value |
| Model | KD-WTGZ-SP/CZ-1500 |
| Max. Size of X/Y Axis | 1500mm |
| Clamping Fixtures Nos | 3个 |
| Elbow Type | Horizontal elbow, vertical elbow |
| Power | 380~415VAC 50~60Hz 1.5kW |
| Air Source | 0.6MPa |
| Equipment Dimension | L1800mm*W1800mm*H900mm |
Features:
The Elbow Busbar Assembly Machine comes with these core advantages. The pneumatic clamping structure maintains stable, uniform alignment of conductors while riveting. This single machine works with horizontal and vertical elbow configurations alike. Three clamping units enable steady multi-point securing. Custom adjustments are available to suit your busbar specifications. Measuring merely 1800 × 1800 × 900 mm, the compact design allows simple integration into existing production arrangements.
Use Cases:
Widely deployed on high- and low-voltage busbar production lines, the busbar elbow assembly machine is engineered for automated assembly of different angled elbows, corner pieces and T-joints. It enables precise alignment, clamping and locking of copper and aluminum busbars and insulated fittings covering a wide range of specifications.
Interfacing with subsequent forming processes in busbar production, it fulfills large-volume manufacturing requirements for elbow busbars used in factory power distribution, building power delivery and industrial power systems.
Capable of substituting manual assembly and supporting uninterrupted assembly line work, it lifts assembly precision and productivity of custom busbars, matching the standardized mass production requirements of smart workshops.
KIANDE provides all-round solutions for various busbar products, and this elbow busbar assembly machine is a representative solution. Buyers who select KIANDE's elbow assembly machines will receive reliable high-quality after-sales service. Boasting 13 years of industry experience and a complete set of professional certifications, KIANDE is a trusted brand offering sturdy equipment and comprehensive services.
